| Product Name: | Mechanical Lifter Unloading System |
|---|---|
| Design Concept: | Positive or Negative Air Pressure |
| Purpose: | To control the wastage discharged from polluting surrounding ambient |
| Function: | Collect the wastage discharged in designated garbage tank using adjustable unloading lifter in seal up manner for periodic disposal |
| Specification Of Mechanical Helicopter System: | (a) Gear Box (CMD): | WVA 175-60 |
|---|---|---|
| (b) Motor Drive: | 7.5kw/10hp/415v/50Hz | |
| (c) HRC Coupling: | MTD HRC 150H 2012 | |
| (d) Chain Coupling: | KC 8018 | |
| (e) Bearing: | UFC 213 D1 NTN Ø2½” | |
| Specification Of Mechanical Rotary Valve: | (a) Worm Gear: | KB 120-60A Ratio60 |
| (b) Motor Drive: | 2.2kw/3ph/415v/50Hz | |
| (c) HRC Coupling: | MTD HRC 110 (H28/F24) | |
| (d) Chain Coupling: | KC 6022 | |
| (e) Bearing: | UFC 280 Ø1½” | |
| Specification Of Mechanical Lifter System: | (a) Worm Gear: | TNRV 110 |
| (b) Motor Drive: | 1.5kw/4ph/415v/50Hz | |
| (c) Shaft: | Ø1½” | |
| (d) Bearing: | UCP 208 Ø1½” | |
| (e) Pulley: | 2 SPA 180/ 1½” Martin Taper Lock | |
| (f) Limit Switch: | MJ – 7208 |
Recommendation
Suitable for all types of dry dust or wastage discharged (Except on liquid form or wastage contains moisture)
Efficiency Level
99.99%
